2X6 Multi Port RJ45 Magnetic Jack 1000 Base - T With LED And Shielded EMI

Basic Information
Place of Origin: GuangDong, China
Brand Name: PHCONN
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: 1262-200036
Minimum Order Quantity: 500 PCS
Price: Negotiable price
Packaging Details: 100 pcs in 1 tray , 36 tray ( 2500pcs ) in carton ; vacuum package,boxes in carton
Delivery Time: 3-15work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union,PAYPAL
Supply Ability: 3,000,000pcs/Month
Contact Now
Detail Information
Type: RJ45 Application: PCB,computers
Color: Customize Material: PBT PA66 PA46,Nylon
Certification: ROHS,ISO9001,CE Class B,ISO 9001,CE Product Name: Metal Shield Multi-port Rj45 Connector With Transformer 180 Degree
Sample: Welcome Ask Sample For Testing Keywords: Multi-port Rj45 Connector,Rj45 Adapter,RJ45 Plug,RJ45 Female Connector,RJ45 Jack

Product Description

2X6 Port RJ45 Magnetic Jack 1000 Base - T RJ45 PCB Jack with LED and Shielded EMI,RJ45 Modular Jack





Part Number
0854-2X6R-G6-F / 0854-2X8R-G6-F / 85728-1008
Application-LAN
ETHERNET(NON PoE)
AutomDX
YES
Bst Circuit
YES
Configuration RX
T,C
Configuration TX
T,C
Contact Mating Area Plating
GOLD 6u"/15u"/30u"
Cores Per Port
9
Diodes
NO DIODES
LED Option
Without LEDS
Latch
UP/Down
Number of Ports
2x6 Port
PCB
FR4
PCB Mount Angle
SIDE ENTRY
PCB Retaining Post
T POST
Pin Type
THT SOLDER
RoHS Compliant
YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search
YES
Shield EMI Tabs
With
Speed
10/100/1000 Magnetics
Temperature
-20 TO 70°C
Turns Ratio RX
1CT:1
Turns Ratio TX
1CT:1



Drawing

2X6 Multi Port RJ45 Magnetic Jack 1000 Base - T With LED And Shielded EMI

2X6 Multi Port RJ45 Magnetic Jack 1000 Base - T With LED And Shielded EMI


Why Choose PengHui



Quality:

World’s Leader supplier of Integrated RJ45 Connector and PCB connector

Except the plating ,From Design tooling, stamping ,Injection molding, assemble, Testing ,packing .All the
step are doing by ourself. So we can control the quality.

  • Manufactured under strict controls.
  • ISO 9001:2008
  • UL Certification
  • Reach Cetitifaction
  • RoHS compliance
  • OEM  for PULSE
  • Active Environmental policy
  • Every module  tested 3times  (not just batch tested)



2X6 Multi Port RJ45 Magnetic Jack 1000 Base - T With LED And Shielded EMI




Unit Price


Charge only 35~60% of Pulse ,Wurth(Midcom), Bothhand Belfuse, Tyco, Halo,....Etc

All the step are doing by ourself. So we can control the cost
PHC have more than 30 units automation equipments to product as possible
PHC consists of 3 subordinations , located partly in  Hunan ,Hubei ,Guangdong (HQ)
With large scale of production lines, we can reach to cost reduction at the most extent

Design &Technical strength


 We have many more than 20years experience in connector industry engineer can support your new
 project.Design a new tooling time:30-45 workdays





Production&Testing

PHC have more than 30 units automation equipments to product as possible
PHC Every  Magnetic RJ45 tested 3times  (not just batch tested)
PHC Every SMT part used Automation testing and packing.





 Automation product line


 2X6 Multi Port RJ45 Magnetic Jack 1000 Base - T With LED And Shielded EMI


Lead Time

With large Popularity of 450 Workers distributed in 4 subsidiary corporations, PHC can offer the fastest
Lead time,and the particular case is according to the situation.



Case.1

Stock

25%

Case.2

3-4 Weeks

70%

Case.3

5-6 Weeks

5%



Service

PHC Offer good pre-sales & after-sales service &Strong technical support

  • New Project: Strong technical and ideal support your new design
  • Existing projects: Try to help customer to save the cost to offer the good quality product and save
  • time.
  • Free Samples:3-5 PCS of each part number
  • Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.
  • Customer complaint:24-48 hours reply 8D report
  • Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,,or repair
  • kits if customers are not satisfied)

Wish To Be Your Best Supplier and Supporter In Your Lan connector Solutions

                                                                                                  -------------  PHC  Sales & Support Team
