Single Port Shielded 4P4C CAT5 RJ11 RJ45 Modular Jack

Basic Information
Place of Origin: GuangDong, China
Brand Name: PHCONN
Certification: ISO9001,SGS,UL,CE,REACH
Minimum Order Quantity: 500 PCS
Price: USD 1.6 ~ 3.0 PCS
Packaging Details: 120 pcs in 1 tray,20 tray in 1 carton
Delivery Time: 3-15 work days
Payment Terms: T/T, L/C, D/A, D/P, PAYPAL
Supply Ability: 2,000,000pcs/Month
Detail Information
Product Name: RJ11 RJ45 Jack Shielding: Shielded
Port: Single Shield Material: Brass Alloy
Plastic: PBT Terminal: Phosphor Copper
Main Products: RJ45, Side Entry Low Profile Rj45 Jack Withstanding Voltage: AC 1500V RMS 50Hz Or 60 Hz 1 Min
Plastic Color: Black PCB: Insert Plate
High Light:

RJ11 RJ45 Modular Jack

,

CAT5 RJ45 Modular Jack

,

Shielded RJ11 RJ45 Connector


Product Description


4P4C Modular Jack RJ11 Connector Phone Jack RJ45 CAT5

Spectifications



1.Current Rating 1.5 amps
2.Voltage Rating 125vac
3.Insulation Resistance 500 MΩmin
4.Contact Resistance 30 MΩmax
5.Withstanding Voltage AC 1000V RMS 50Hz or 60Hz 1 min



Service

PHC Offer good pre-sales & after-sales service &Strong technical support

1. New Project: Strong technical and ideal support your new design

2. Existing projects: Try to help customer to save the cost to offer the good quality product and save

3. time.

4. Free Samples:3-5 PCS of each part number

5. Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.

6. Customer complaint:24-48 hours reply 8D report

7. Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,,or repair

8. kits if customers are not satisfied)



Mechanical



1.Insertion Force

2 CONTACTS....350g

4 CONTACTS….500g

6 CONTACTS….750g

8 CONTACTS….900g

10 CONTACTS....1050g

2.Retention Strength

7.7KG.F min between jack and plug

3.Durability

750 mating cycles min



Material



1.Housing

ABS RESIN(UL94V-0) PBT(UL94V-0) PA66(UL94V-0) PA46(UL94V-0) LCP(UL94V-0)

2.Contact Wire

Diameter 0.45mm phosphor bronze gold plating over nickel  0.35mm

thickness phosphor bronze alloy selective gold plating over nickel

3.Shield

0.20~0.25mm thickness brass with tin plated

4.Gold Plating

1u inch,3u inch,6u inch,15u inch,30u inch,50u inch

6.RoHS peak wave

 solder

RoHS peak wave solder temperature rating 240°C±5°C
