Vertical Single Port Top Entry 1000M PHC RJ45 Ethernet Jack

Basic Information
Place of Origin: GuanDong , China ( Mainland )
Brand Name: PHCONN
Certification: ISO9001 : 2008 , SGS , RoHs
Model Number: 1110-2080100T
Minimum Order Quantity: 500 PCS
Price: USD 0.15 ~ 0.5 PCS
Packaging Details: 70 pcs in 1 tray , 36 tray ( 2500pcs ) in carton ;
Delivery Time: 7 - 10 Work Days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 5,000,000 PCS / Month
Detail Information
Product Name: RJ45 Gold-plated:: Fu" , 1u" , 3u" , 6u" , 15u" , 30u" , 50u"
Application: PCB Gender: Female
OEM/ODM: OEM Service Offered Design Service Offered Buyer Label Offered Color: Option
Type: SMD Connector Pin Number: 6 Pin
High Light:

PHC RJ45 Ethernet Jack

,

Vertical 1000M RJ45 Ethernet Jack

,

6P6C Single Port RJ45 Ethernet Connector


Product Description


Vertical Ethernet 1000M RJ45 Single-Port Top Entry Jack Through Hole



Description



Cat6 / Cat5e RJ45 Connector, Ethernet Cable Crimp Connectors Network Plug for Solid Wire and Standard Cable

100 pcs Rj45 plugs for unshielded twisted pair solid or stranded cable, supports 24 to 26 AWG round or flat network cable,Gold-plated contacts provides reliable performance for a Gigabit Ethernet rated network Save money by using these connectors to create your own patch cables ROHS compliant, Easy for Carry, Gold plated connectors resist corrosion, improve the signal performance



Wide application:



Widely used in all kinds of mobile phone charging interface, digital camera, electronic toys, digital home appliances, computer motherboard, display, network switch, telephone, set-top box, POS machine, LED display, etc.



Spectifications


Part Number

Manufacturer
Part Number

Manufacturer

Description

1110-2080100T

1110-2080100T

PHC

180 Degree SMD RJ11 RJ45 6P6C Modular Jack Single Port Female Connector



Series

Connector Type

Applications

Mounting Type

Connectors, Interconnects

PHC RJ45 Female

Jack

SMD



Orientation

Termination

LED Color

Shielding

180° Angle (Right) top enter

Solder

No

Without Shielded







Electrical



1.Current Rating 1.5 amps
2.Voltage Rating 125vac
3.Insulation Resistance 500 MΩmin
4.Contact Resistance 30 MΩmax
5.Withstanding Voltage AC 1000V RMS 50Hz or 60Hz 1 min



Mechanical



1.Insertion Force

2 CONTACTS....350g

4 CONTACTS….500g

6 CONTACTS….750g

8 CONTACTS….900g

10 CONTACTS....1050g

2.Retention Strength

7.7KG.F min between jack and plug

3.Durability

750 mating cycles min



Material



1.Housing

ABS RESIN(UL94V-0) PBT(UL94V-0) PA66(UL94V-0) PA46(UL94V-0) LCP(UL94V-0)

2.Contact Wire

Diameter 0.45mm phosphor bronze gold plating over nickel  0.35mm

thickness phosphor bronze alloy selective gold plating over nickel

3.Shield

0.20~0.25mm thickness brass with tin plated

4.Gold Plating

1u inch,3u inch,6u inch,15u inch,30u inch,50u inch

6.RoHS peak wave

 solder

RoHS peak wave solder temperature rating 240°C±5°C




Why Choose PengHui

Quality :

World’s Leader supplier of Integrated RJ45 Connector and PCB connector

Except the plating , From Design tooling , stamping , Injection molding , assemble , Testing , packing .All the step are doing by ourself . So we can control the quality .



  Manufactured under strict controls

  RoHS compliance

  ISO 9001:2008

  OEM  for PULSE

  UL Certification

  Active Environmental policy

  Reach Cetitifaction

 Every module  tested 3times  (not just batch tested)



Unit Price

Charge only 35% ~ 60% of Pulse , (Midcom), Bothhand Belfuse, Tyco, Halo,....Etc

All the step are doing by ourself. So we can control the cost
PHC have more than 30 units automation equipments to product as possible
PHC consists of 3 subordinations , located partly in  Hunan ,Hubei ,Guangdong .
With large scale of production lines, we can reach to cost reduction at the most extent

Production&Testing

PHC have more than 30 units automation equipments to product as possible
PHC Every  Magnetic RJ45 tested 3times  (not just batch tested)
PHC Every SMT part used Automation testing and packing.

Service

PHC Offer good pre-sales & after-sales service &Strong technical support




1. New Project: Strong technical and ideal support your new design
2.Existing projects:Try to help customer to save the cost to offer the good quality product and save time.
3. Free Samples:3-5 PCS of each part number.
4. Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.
5. Customer complaint:24-48 hours reply 8D report.

6. Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,
    or repair kits if customers are not satisfied)



Lead Time

With large Popularity of 450 Workers distributed in 4 subsidiary corporations, PHC can offer the fastest
Lead time,and the particular case is according to the situation.



Case.1

Stock

25%

Case.2

3-4 Weeks

70%

Case.3

5-6 Weeks

5%



Design &Technical strength


We have many more than 20years experience in connector industry engineer can support your new
project.Design a new tooling time : 30-45 workdays

PHC Patented product in China
